Product Details
Place of Origin: China
Brand Name: Yuka
Payment & Shipping Terms
Minimum Order Quantity: 50pcs
Price: Negotiable
Packaging Details: Box Package
Delivery Time: 3-7working days
Payment Terms: L/C,T/T
Supply Ability: 300,000pcs/month
Model No.: |
YF-B100 ACS |
Material: |
Aluminum Alloy |
Housing Serve Lige: |
15 Years |
Element Serve Life: |
6000~8000 Hours |
Filtration Performance: |
From 5 μm To 0.01μm |
Maxi. Operate Pressure: |
1.6 Mpa |
Operate Temperature: |
1.5~80ºc |
Connection: |
Rc2 1/2" |
Flow Rate: |
13.0 M³/Min |
Resistance Corrosion: |
Inside And Outside |
Color: |
Light Blue |
Trademark: |
Yuka |
Transport Package: |
Brown Inner Box & Cardboard |
Specification: Dimension: |
174 X 142x 558mm |
HS Code: |
8421399090 |
Clapboard: |
Without Clapboard |
Filter Number: |
1 |
Medium Material: |
Fiberglass |
Efficiency: |
F5 |
Filtration Grade: |
Medium Filter |
Type: |
Cartridge Filter |
Place Of Origin: |
China |
Model No.: |
YF-B100 ACS |
Material: |
Aluminum Alloy |
Housing Serve Lige: |
15 Years |
Element Serve Life: |
6000~8000 Hours |
Filtration Performance: |
From 5 μm To 0.01μm |
Maxi. Operate Pressure: |
1.6 Mpa |
Operate Temperature: |
1.5~80ºc |
Connection: |
Rc2 1/2" |
Flow Rate: |
13.0 M³/Min |
Resistance Corrosion: |
Inside And Outside |
Color: |
Light Blue |
Trademark: |
Yuka |
Transport Package: |
Brown Inner Box & Cardboard |
Specification: Dimension: |
174 X 142x 558mm |
HS Code: |
8421399090 |
Clapboard: |
Without Clapboard |
Filter Number: |
1 |
Medium Material: |
Fiberglass |
Efficiency: |
F5 |
Filtration Grade: |
Medium Filter |
Type: |
Cartridge Filter |
Place Of Origin: |
China |
Feature & Benefit
* Maxi.working pressure: 16 bar (232CFM),Maxi.working temperature: 80℃
* Rc1/2" to Rc 4" BSP connection, 1m³/min to 48 m³/min capacity
* Ball Valve for Water Drain System,Instead ofn auto drain trap, avoid unexpected blockages
* Internal & External with anti-corrision treatment
* Removed particles dust diameter up to 0.01 Micron, Oil residual content less than 0.003mg/m³
-PF (5 μm) pre-filter
-AO (1 μm) precise air filter
-AA (0.01 μm) Ultra air filter
-AX (0.01 μm) After-filter
-ACS (0.003mg/m³) Activated Carbon, removed oil aerosol and vapour
-AR (1 μm), removed dust particle only
-AAR (0.01 μm), removed dust particle
Product Picture
Technical Specification
| Model | Pipe size | Flow rates | Dimension (mm) | |||||||
| L/S | m³/min | scfm | W(Width) | D(Depth) | H(Height) | A | B | C | ||
| YF-B010 | RC1/2" | 16.7 | 1.0 | 35.5 | 96 | 79 | 245 | 29 | 223 | 118 |
| YF-B020 | RC3/4" | 25.0 | 1.5 | 53.0 | 96 | 79 | 245 | 29 | 223 | 118 |
| YF-B030 | RC3/4" | 30.0 | 1.8 | 63.6 | 96 | 79 | 274 | 29 | 257 | 153 |
| YF-B040 | RC1" | 33.3 | 2.0 | 71.0 | 96 | 79 | 274 | 29 | 257 | 153 |
| YF-B060 | RC1" | 60.0 | 3.6 | 127.0 | 138 | 111 | 349 | 37 | 421 | 303 |
| YF-B070 | RC1" | 83.3 | 5.0 | 177.0 | 138 | 111 | 450 | 37 | 421 | 303 |
| YF-B080 | RC1-1/2" | 125.0 | 7.5 | 265.0 | 138 | 111 | 450 | 37 | 421 | 303 |
| YF-B090 | RC2" | 166.7 | 10.0 | 353.1 | 174 | 142 | 558 | 58 | 500 | 467 |
| YF-B100 | RC2-1/2" | 216.7 | 13.0 | 459.0 | 174 | 142 | 558 | 58 | 780 | 794 |
| YF-B110 | RC2" | 283.3 | 17.0 | 600.0 | 174 | 142 | 838 | 58 | 780 | 794 |
| YF-B120 | RC2-1/2" | 316.7 | 19.0 | 671.0 | 174 | 142 | 838 | 74 | 571 | 514 |
| YF-B130 | RC3" | 416.7 | 25.0 | 883.0 | 220 | 184 | 616 | 74 | 571 | 514 |
| YF-B140 | RC4" | 466.7 | 28.0 | 989.0 | 220 | 184 | 616 | 74 | 571 | 514 |
| YF-B150 | RC3" | 683.3 | 41.0 | 1448.0 | 220 | 184 | 892 | 74 | 828 | 764 |
| YF-B160 | RC4" | 800.0 | 48.0 | 1695.0 | 220 | 184 | 892 | 74 | 828 | 764 |
| Technical requirements | Maxi. operating pressure: 16 barg Operating temperature: 1.5°C~80°C | |||||||||
| Pressure | Barg | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | 11 | 12 | 13 | 14 | 15 | 16 |
| Psig | 15 | 29 | 44 | 59 | 73 | 87 | 100 | 116 | 131 | 145 | 160 | 174 | 189 | 203 | 219 | 232 | |
| Correction factor | 0.38 | 0.53 | 0.65 | 0.76 | 0.85 | 0.93 | 1.00 | 1.07 | 1.13 | 1.19 | 1.23 | 1.31 | 1.36 | 1.41 | 1.46 | 1.51 | |
